Installation Guide
9
Cable routing holes
When routing cables to connect to the projector through a wall, use positions (
ᵟ
) and ( ) in the following
figure as the cable routing holes.
Vertical slide adjustment range
[Unit: mm]
Horizontal slide adjustment range
[Unit: mm]
Forward/backward slide adjustment range
Arm slide adjustment range
[Unit: mm]
To Next Page
