Installation Guide
23
EB-580/570 (4:3 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
75" 152.4x114.3 18.9 - 31.1 19.8 114.3
76" 154.4x115.8 19.6 - 31.1 20.1 115.8
77" 156.5x117.3 20.2 - 31.1 20.3 117.3
78" 158.5x118.9 20.9 - 31.1 20.6 118.9
79" 160.5x120.4 21.6 - 31.1 20.8 120.4
80" 162.6x121.9 22.2 - 31.1 21.1 121.9
81" 164.6x123.4 22.9 - 31.1 21.3 123.4
82" 166.6x125.0 23.6 - 31.1 21.5 125.0
83" 168.7x126.5 24.2 - 31.1 21.8 126.5
84" 170.7x128.0 24.9 - 31.1 22.0 128.0
85" 172.7x129.5 25.6 - 31.1 22.3 129.5
86" 174.8x131.1 26.2 - 31.1 22.5 131.1
87" 176.8x132.6 26.9 - 31.1 22.8 132.6
88" 178.8x134.1 27.5 - 31.1 23.0 134.1
89" 180.8x135.6 28.2 - 31.1 23.3 135.6
90" 182.9x137.2 28.9 - 31.1 23.5 137.2
91" 184.9x138.7 29.5 - 31.1 23.8 138.7
92" 186.9x140.2 30.2 - 31.1 24.0 140.2
93" 189.0x141.7 30.9 - 31.1 24.2 141.7
Images larger than 93 inches are not projected correctly.
EB-580/570 (16:9 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
75" 166.0x93.4 23.4 - 31.1 37.0 93.4
76" 168.2x94.6 24.1 - 31.1 37.5 94.6
77" 170.5x95.9 24.8 - 31.1 38.0 95.9
78" 172.7x97.1 25.5 - 31.1 38.5 97.1
