Epson EB-580 Installation Guide

Installation Guide
17
EB-580/570 (4:3 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
56" 113.8x85.3 6.3 - 19.3 15.0 - 28.0 15.2 85.3
57" 115.8x86.9 6.9 - 20.2 15.6 - 28.9 15.4 86.9
58" 117.9x88.4 7.6 - 21.1 16.3 - 29.8 15.6 88.4
59" 119.9x89.9 8.3 - 22.0 17.0 - 30.7 15.9 89.9
60" 121.9x91.4 8.9 - 22.9 17.6 - 31.6 16.1 91.4
61" 124.0x93.0 9.6 - 23.8 18.3 - 32.5 16.4 93.0
62" 126.0x94.5 10.3 - 24.7 19.0 - 33.4 16.6 94.5
63" 128.0x96.0 10.9 - 25.6 19.6 - 34.3 16.9 96.0
64" 130.0x97.5 11.6 - 26.5 20.3 - 35.2 17.1 97.5
65" 132.1x99.1 12.2 - 27.4 20.9 - 36.1 17.4 99.1
66" 134.1x100.6 12.9 - 28.3 21.6 - 37.0 17.6 100.6
67" 136.1x102.1 13.6 - 29.2 22.3 - 37.9 17.9 102.1
68" 138.2x103.6 14.2 - 30.1 22.9 - 38.8 18.1 103.6
69" 140.2x105.2 14.9 - 31.0 23.6 - 39.7 18.3 105.2
70" 142.2x106.7 15.6 - 31.1 24.3 - 39.8 18.6 106.7
71" 144.3x108.2 16.2 - 31.1 24.9 - 39.8 18.8 108.2
72" 146.3x109.7 16.9 - 31.1 25.6 - 39.8 19.1 109.7
73" 148.3x111.3 17.6 - 31.1 26.3 - 39.8 19.3 111.3
74" 150.4x112.8 18.2 - 31.1 26.9 - 39.8 19.6 112.8
Images smaller than 56 inches are not projected correctly.
EB-580/570 (16:9 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
52" 115.1x64.8 6.7 - 19.9 15.4 - 28.6 26.1 64.8
53" 117.3x66.0 7.4 - 20.9 16.1 - 29.6 26.6 66.0
54" 119.5x67.2 8.1 - 21.8 16.8 - 30.5 27.1 67.2
55" 121.8x68.5 8.9 - 22.8 17.6 - 31.5 27.5 68.5
