Epson EB-580 - EB-580;570 (16:10 Projected Image)

Installation Guide
24
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
79" 174.9x98.4 26.3 - 31.1 38.9 98.4
80" 177.1x99.6 27.0 - 31.1 39.4 99.6
81" 179.3x100.9 27.7 - 31.1 39.9 100.9
82" 181.5x102.1 28.4 - 31.1 40.4 102.1
83" 183.7x103.4 29.2 - 31.1 40.8 103.4
84" 186.0x104.6 29.9 - 31.1 41.3 104.6
85" 188.2x105.8 30.6 - 31.1 41.8 105.8
Images larger than 85 inches are not projected correctly.
EB-580/570 (16:10 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
75" 161.5x101.0 21.9 - 31.1 31.0 101.0
76" 163.7x102.3 22.6 - 31.1 31.4 102.3
77" 165.9x103.7 23.3 - 31.1 31.8 103.7
78" 168.0x105.0 24.0 - 31.1 32.2 105.0
79" 170.2x106.3 24.7 - 31.1 32.6 106.3
80" 172.3x107.7 25.4 - 31.1 33.0 107.7
81" 174.5x109.0 26.1 - 31.1 33.4 109.0
82" 176.6x110.4 26.8 - 31.1 33.8 110.4
83" 178.8x111.7 27.5 - 31.1 34.2 111.7
84" 180.9x113.1 28.2 - 31.1 34.6 113.1
85" 183.1x114.4 28.9 - 31.1 35.0 114.4
86" 185.2x115.8 29.7 - 31.1 35.4 115.8
87" 187.4x117.1 30.4 - 31.1 35.8 117.1
88" 189.5x118.5 31.1* 36.2 118.5
*
Figure for Wide (maximum zoom).
Images larger than 88 inches are not projected correctly.
