Epson EB-580 Installation Guide

Installation Guide
18
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
56" 124.0x69.7 9.6 - 23.8 18.3 - 32.5 28.0 69.7
57" 126.2x71.0 10.3 - 24.8 19.0 - 33.5 28.5 71.0
58" 128.4x72.2 11.0 - 25.8 19.7 - 34.5 29.0 72.2
59" 130.6x73.5 11.8 - 26.7 20.5 - 35.4 29.4 73.5
60" 132.8x74.7 12.5 - 27.7 21.2 - 36.4 29.9 74.7
61" 135.0x76.0 13.2 - 28.7 21.9 - 37.4 30.4 76.0
62" 137.3x77.2 13.9 - 29.7 22.6 - 38.4 30.9 77.2
63" 139.5x78.5 14.7 - 30.6 23.4 - 39.3 31.3 78.5
64" 141.7x79.7 15.4 - 31.1 24.1 - 39.8 31.8 79.7
65" 143.9x80.9 16.1 - 31.1 24.8 - 39.8 32.3 80.9
66" 146.1x82.2 16.8 - 31.1 25.5 - 39.8 32.8 82.2
67" 148.3x83.4 17.6 - 31.1 26.3 - 39.8 33.2 83.4
68" 150.5x84.7 18.3 - 31.1 27.0 - 39.8 33.7 84.7
69" 152.8x85.9 19.0 - 31.1 27.7 - 39.8 34.2 85.9
70" 155.0x87.2 19.7 - 31.1 28.4 - 39.8 34.7 87.2
71" 157.2x88.4 20.5 - 31.1 29.2 - 39.8 35.1 88.4
72" 159.4x89.7 21.2 - 31.1 29.9 - 39.8 35.6 89.7
73" 161.6x90.9 21.9 - 31.1 30.6 - 39.8 36.1 90.9
74" 163.8x92.1 22.6 - 31.1 31.3 - 39.8 36.6 92.1
Images smaller than 52 inches are not projected correctly.
EB-580/570 (16:10 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
53" 114.2x71.3 6.4 - 19.5 15.1 - 28.2 22.3 71.3
54" 116.3x72.7 7.1 - 20.4 15.8 - 29.1 22.7 72.7
55" 118.5x74.0 7.8 - 21.4 16.5 - 30.1 23.1 74.0
56" 120.6x75.4 8.5 - 22.3 17.2 - 31.0 23.5 75.4
57" 122.8x76.7 9.2 - 23.3 17.9 - 32.0 23.9 76.7
58" 124.9x78.1 9.9 - 24.2 18.6 - 32.9 24.3 78.1
59" 127.1x79.4 10.6 - 25.2 19.3 - 33.9 24.7 79.4
