Epson EB-580 Installation Guide

Installation Guide
15
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
67" 148.3x83.4 11.7 - 26.7 20.4 - 35.4 24.4 83.4
68" 150.5x84.7 12.4 - 27.6 21.1 - 36.3 24.8 84.7
69" 152.8x85.9 13.0 - 28.4 21.7 - 37.1 25.1 85.9
70" 155.0x87.2 13.7 - 29.3 22.4 - 38.0 25.4 87.2
71" 157.2x88.4 14.3 - 30.1 23.0 - 38.8 25.8 88.4
72" 159.4x89.7 14.9 - 31.0 23.6 - 39.7 26.1 89.7
73" 161.6x90.9 15.6 - 31.1 24.3 - 39.8 26.5 90.9
74" 163.8x92.1 16.2 - 31.1 24.9 - 39.8 26.8 92.1
Images smaller than 59 inches are not projected correctly.
EB-585Wi/585W/575Wi/575W (4:3 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
53" 107.7x80.8 6.2 - 19.3 14.9 - 28.0 17.4 80.8
54" 109.7x82.3 6.9 - 20.2 15.6 - 28.9 17.7 82.3
55" 111.8x83.8 7.6 - 21.2 16.3 - 29.9 18.0 83.8
56" 113.8x85.3 8.3 - 22.1 17.0 - 30.8 18.3 85.3
57" 115.8x86.9 9.1 - 23.1 17.8 - 31.8 18.6 86.9
58" 117.9x88.4 9.8 - 24.0 18.5 - 32.7 18.9 88.4
59" 119.9x89.9 10.5 - 25.0 19.2 - 33.7 19.2 89.9
60" 121.9x91.4 11.2 - 25.9 19.9 - 34.6 19.5 91.4
61" 124.0x93.0 11.9 - 26.9 20.6 - 35.6 19.8 93.0
62" 126.0x94.5 12.6 - 27.8 21.3 - 36.5 20.1 94.5
63" 128.0x96.0 13.3 - 28.8 22.0 - 37.5 20.4 96.0
64" 130.0x97.5 14.0 - 29.7 22.7 - 38.4 20.7 97.5
65" 132.1x99.1 14.7 - 30.7 23.4 - 39.4 21.0 99.1
66" 134.1x100.6 15.4 - 31.1 24.1 - 39.8 21.3 100.6
67" 136.1x102.1 16.1 - 31.1 24.8 - 39.8 21.6 102.1
68" 138.2x103.6 16.8 - 31.1 25.5 - 39.8 21.9 103.6
69" 140.2x105.2 17.5 - 31.1 26.2 - 39.8 22.2 105.2
70" 142.2x106.7 18.2 - 31.1 26.9 - 39.8 22.5 106.7
