Epson EB-580 Installation Guide

Installation Guide
14
EB-585Wi/585W/575Wi/575W (16:10 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
60" 129.2x80.8 6.2 - 19.3 14.9 - 28.0 17.4 80.8
61" 131.4x82.1 6.9 - 20.1 15.6 - 28.8 17.7 82.1
62" 133.5x83.5 7.5 - 20.9 16.2 - 29.6 17.9 83.5
63" 135.7x84.8 8.1 - 21.8 16.8 - 30.5 18.2 84.8
64" 137.9x86.2 8.7 - 22.6 17.4 - 31.3 18.5 86.2
65" 140.0x87.5 9.3 - 23.5 18.0 - 32.2 18.7 87.5
66" 142.2x88.8 10.0 - 24.3 18.7 - 33.0 19.0 88.8
67" 144.3x90.2 10.6 - 25.1 19.3 - 33.8 19.3 90.2
68" 146.5x91.5 11.2 - 26.0 19.9 - 34.7 19.5 91.5
69" 148.6x92.9 11.8 - 26.8 20.5 - 35.5 19.8 92.9
70" 150.8x94.2 12.4 - 27.6 21.1 - 36.3 20.1 94.2
71" 152.9x95.6 13.1 - 28.5 21.8 - 37.2 20.3 95.6
72" 155.1x96.9 13.7 - 29.3 22.4 - 38.0 20.6 96.9
73" 157.2x98.3 14.3 - 30.2 23.0 - 38.9 20.9 98.3
74" 159.4x99.6 14.9 - 31.0 23.6 - 39.7 21.1 99.6
Images smaller than 60 inches are not projected correctly.
EB-585Wi/585W/575Wi/575W (16:9 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
59" 130.6x73.5 6.6 - 19.8 15.3 - 28.5 21.7 73.5
60" 132.8x74.7 7.3 - 20.7 16.0 - 29.4 22.0 74.7
61" 135.0x76.0 7.9 - 21.5 16.6 - 30.2 22.3 76.0
62" 137.3x77.2 8.6 - 22.4 17.3 - 31.1 22.7 77.2
63" 139.5x78.5 9.2 - 23.3 17.9 - 32.0 23.0 78.5
64" 141.7x79.7 9.8 - 24.1 18.5 - 32.8 23.4 79.7
65" 143.9x80.9 10.5 - 25.0 19.2 - 33.7 23.7 80.9
66" 146.1x82.2 11.1 - 25.8 19.8 - 34.5 24.1 82.2
