Installation Guide
22
EB-585Wi/585W/575Wi/575W (4:3 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
75" 152.4x114.3 21.7 - 31.1 24.1 114.3
76" 154.4x115.8 22.4 - 31.1 24.4 115.8
77" 156.5x117.3 23.1 - 31.1 24.7 117.3
78" 158.5x118.9 23.8 - 31.1 25.0 118.9
79" 160.5x120.4 24.5 - 31.1 25.3 120.4
80" 162.6x121.9 25.2 - 31.1 25.6 121.9
81" 164.6x123.4 25.9 - 31.1 25.9 123.4
82" 166.6x125.0 26.6 - 31.1 26.2 125.0
83" 168.7x126.5 27.3 - 31.1 26.5 126.5
84" 170.7x128.0 28.0 - 31.1 26.8 128.0
85" 172.7x129.5 28.7 - 31.1 27.1 129.5
86" 174.8x131.1 29.4 - 31.1 27.4 131.1
87" 176.8x132.6 30.1 - 31.1 27.7 132.6
88" 178.8x134.1 30.8 - 31.1 28.0 134.1
Images larger than 88 inches are not projected correctly.
