Installation Guide
21
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
100" 215.4x134.6 31.1* 28.1 134.6
*
Figure for Wide (maximum zoom).
Images larger than 100 inches are not projected correctly.
EB-585Wi/585W/575Wi/575W (16:9 projected image)
[Unit: cm]
S
Projected image size
a
Projection Dis‐
tance
Minimum (Wide)
to Maximum
(Tele)
b
Numbers on the
arm slide scale
c
Distance from
projected image
to wall plate
h
Height of projec‐
ted image
75" 166.0x93.4 16.8 - 31.1 27.2 93.4
76" 168.2x94.6 17.5 - 31.1 27.5 94.6
77" 170.5x95.9 18.1 - 31.1 27.8 95.9
78" 172.7x97.1 18.8 - 31.1 28.2 97.1
79" 174.9x98.4 19.4 - 31.1 28.5 98.4
80" 177.1x99.6 20.0 - 31.1 28.9 99.6
81" 179.3x100.9 20.7 - 31.1 29.2 100.9
82" 181.5x102.1 21.3 - 31.1 29.6 102.1
83" 183.7x103.4 21.9 - 31.1 29.9 103.4
84" 186.0x104.6 22.6 - 31.1 30.3 104.6
85" 188.2x105.8 23.2 - 31.1 30.6 105.8
86" 190.4x107.1 23.9 - 31.1 30.9 107.1
87" 192.6x108.3 24.5 - 31.1 31.3 108.3
88" 194.8x109.6 25.1 - 31.1 31.6 109.6
89" 197.0x110.8 25.8 - 31.1 32.0 110.8
90" 199.2x112.1 26.4 - 31.1 32.3 112.1
91" 201.5x113.3 27.0 - 31.1 32.7 113.3
92" 203.7x114.6 27.7 - 31.1 33.0 114.6
93" 205.9x115.8 28.3 - 31.1 33.3 115.8
94" 208.1x117.1 29.0 - 31.1 33.7 117.1
95" 210.3x118.3 29.6 - 31.1 34.0 118.3
96" 212.5x119.5 30.2 - 31.1 34.4 119.5
97" 214.7x120.8 30.9 - 31.1 34.7 120.8
Images larger than 97 inches are not projected correctly.
