Connector Specifications
250
Computer port 1 Mini D-Sub15-pin (female)
Monitor Out port 1 Mini D-Sub15-pin (female)
Video port 1 RCA pin jack
Audio ports 2 Stereo mini pin jack
Mic port (EB‑710Ui) 1 Stereo mini pin jack
Audio Out port 1 Stereo mini pin jack
HDMI1/MHL port 1 HDMI (Audio is only supported by
PCM)
HDMI2 port 1 HDMI (Audio is only supported by
PCM)
HDMI3 port 1 HDMI (Audio is only supported by
PCM)
USB-A ports 2 USB connector (Type A)
USB-B port 1 USB connector (Type B)
USB port (for Wireless
LAN module)
1 USB connector (Type A)
LAN port 1 RJ-45
RS-232C port 1 Mini D-Sub 9-pin (male)
SYNC ports (EB‑710Ui) 2 Stereo mini pin jack
TCH port (EB‑710Ui) 1 Mini DIN 8-pin
a
• USB-A and USB-B port supports USB 2.0. However, USB ports are
not guaranteed to operate all devices that support USB.
• USB-B port does not support USB 1.1.
