Name Function
Y
[Memory] button
Performs operations and makes settings for the memory
function.
s "Memory Function" p.121
Z
[E-Zoom] buttons
[z][x]
Enlarges or reduces the image without changing the
projection size.
s "Enlarging Part of the Image (E-Zoom)" p.118
a
[Default] button
Enabled when [Default]: Reset is displayed on the
configuration menu guide. The settings being adjusted are
returned to their default values.
s "Using the Configuration Menu" p.132
b
[Esc] button
• Stops the current function.
• If pressed when the Configuration menu is displayed, it
moves to the previous level.
s "Using the Configuration Menu" p.132
• Acts as a mouse's right button when using the optional
wireless mouse receiver.
s "Optional Accessories" p.215
c
[Focus] button
Each time the button is pressed, the adjustment screens for
focus and distortion are displayed in that order.
s "Correcting the Focus" p.37
d
[Split] button
Each time the button is pressed, the image changes
between projecting two images simultaneously by
splitting the projected screen, or projecting one image as
normal.
s "Projecting Two Images Simultaneously (Split Screen)
" p.114
e
[Color Mode] button
Each time the button is pressed, the Color Mode changes.
s "Selecting the Projection Quality (Selecting Color
Mode)" p.86
f
[Search] button
Changes to the next input source that is sending an image.
s "Automatically Detecting Input Signals and Changing
the Projected Image (Source Search)" p.59
Name Function
g
[ ] button
Illuminates the buttons on the remote control for
approximately 15 seconds. This is useful when using the
remote control in the dark.
h
Indicator
A light is emitted when outputting remote control signals.
i
Remote control light-
emitting area
Outputs remote control signals.
Part Names and Functions
21
