Epson Expression 1680 - Scanner Parts

1-6
Getting to Know Your Scanner
R4C6740
Setup Guide Rev. C
KNOW.FM A5 size
10/19/00
L
Proof Sign-off:
K.Pipa
J.Miyakoshi
K.Norum
Scanner Parts
carriage
(in the home position)
document table
operate button
ERROR light
document cover
READY light
start button
option interface connector SCSI ID rotary switch
AC inlet
USB interface connector
transportation lock lever
optional interface slot
SCSI interface connectors
SCSI terminator switch
