Epson Expression 1680 Setup Guide

iii
R
Proof Sign-off:
K.Pipa
J.Miyakoshi
K.Norum
R4C6740
Setup Guide Rev. C
SETUPG.TOC A5 size
10/19/00
Contents
Safety Instructions
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warnings, Cautions, and Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
E
NERGY
S
TAR
®
Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
For United Kingdom Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 1 Getting to Know Your Scanner
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Unpacking the Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Scanner Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Lights and Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Chapter 2 Setting Up the Scanner
Choosing a Place for the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Releasing the Transportation Lock . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Plugging in the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Checking Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Connecting the Scanner Using the SCSI Interface . . . . . . . . . . . . 2-7
Installing a SCSI interface board . . . . . . . . . . . . . . . . . . . . . . 2-8
Understanding SCSI connections. . . . . . . . . . . . . . . . . . . . . . 2-9
Setting the SCSI ID number . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Setting the terminator switch . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Connecting the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Power-on sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Power-off sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
When changing the ID number or replacing the
SCSI board in Windows 98. . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Epson Expression 1680 Specifications

Scanning Specifications

optical resolution	1600 x 3200 dpi
maximum resolution	13, 600 x 18, 720 dpi with interpolation
effective pixels	13, 600 x 18, 720 pixels (1600 dpi)
color depth	48 bits per pixel internal/external
grayscale depth	16 bits per pixel internal/external
scanning speed (color, 1600 dpi, draft mode)	9.2 msec/line (approx.)
scanning speed (grayscale/monochrome, 1600 dpi, draft mode)	3.1 msec/line (approx.)

Operating Environment

temperature operating range	41ºF to 95ºF (5ºC to 35ºC)
humidity operating range	10% to 80% (no condensation)
humidity storage range	10% to 85% (no condensation)

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption (operating without optional unit)	60W
power consumption (operating with optional unit)	75W
power consumption (standby without optional unit)	10W

Weight and Dimensions

maximum read area	8.5" x 11.7" (216mm x 297mm)
width	13.1" (332mm)
depth	22.1" (562mm)
height	5.2" (133mm)
weight	18.7 lb (8.5 kg approx.)
