Connecting the Scanner Using the USB Interface . . . . . . . . . . . . 2-18
Understanding USB connections . . . . . . . . . . . . . . . . . . . . . 2-18
Connecting the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
When changing the USB port in Windows 98. . . . . . . . . . . 2-21
Chapter 3 Installing the Software
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
When connecting the scanner directly to
your computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
When scanning over a network. . . . . . . . . . . . . . . . . . . . . . . 3-5
Installing EPSON TWAIN Pro for Windows . . . . . . . . . . . . . . . . 3-6
For Windows Millennium Edition users . . . . . . . . . . . . . . . 3-7
For Windows 2000 users . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
For Windows 98 users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Installing other scanner software for
Windows Millennium Edition, 98, and 2000 . . . . . . . . . 3-17
For Windows 95 and Windows NT 4.0 users . . . . . . . . . . . 3-19
Installing EPSON TWAIN Pro for Macintosh . . . . . . . . . . . . . . . 3-25
Installing Software for Scanning Over a Network . . . . . . . . . . . 3-27
Installing EPSON Scan Server . . . . . . . . . . . . . . . . . . . . . . . . 3-27
Setting the Scanner Server PC's IP Address . . . . . . . . . . . . 3-36
Installing EPSON TWAIN Pro Network . . . . . . . . . . . . . . . 3-37
Selecting Scanners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
For Windows Millennium Edition, 98, and 2000 users . . . 3-44
For Macintosh users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
When Updating Your Windows Operating System . . . . . . . . . . 3-48
Uninstalling the Scanner Software for Windows . . . . . . . . . . . . 3-49

Epson Expression 1680 Specifications

Scanning Specifications

optical resolution	1600 x 3200 dpi
maximum resolution	13, 600 x 18, 720 dpi with interpolation
effective pixels	13, 600 x 18, 720 pixels (1600 dpi)
color depth	48 bits per pixel internal/external
grayscale depth	16 bits per pixel internal/external
scanning speed (color, 1600 dpi, draft mode)	9.2 msec/line (approx.)
scanning speed (grayscale/monochrome, 1600 dpi, draft mode)	3.1 msec/line (approx.)

Operating Environment

temperature operating range	41ºF to 95ºF (5ºC to 35ºC)
humidity operating range	10% to 80% (no condensation)
humidity storage range	10% to 85% (no condensation)

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption (operating without optional unit)	60W
power consumption (operating with optional unit)	75W
power consumption (standby without optional unit)	10W

Weight and Dimensions

maximum read area	8.5" x 11.7" (216mm x 297mm)
width	13.1" (332mm)
depth	22.1" (562mm)
height	5.2" (133mm)
weight	18.7 lb (8.5 kg approx.)
