5. Select EPSON Expression 1680 and click Remove.
Note:
If other devices listed in the Scanners and Cameras Properties dialog
box are not connected to the computer when you click Remove,
those devices may also be removed. Be sure to connect and turn on
all the devices listed in the Scanners and Cameras Properties dialog
box before turning on your computer and removing the scanner.
6. Click OK to close the dialog box, then close the Control Panel.
7. Shut down Windows and turn off your computer, but leave
the scanner on.
8. Connect the USB cable to the new USB port.
9. Turn on your computer.
10. When the dialog box below appears, insert your scanner
software CD into your CD-ROM drive, then click OK to
reinstall EPSON TWAIN Pro.
Note:
If the following dialog box appears, browse the CD-ROM for
EPSON\language\Win98, then click OK.

Epson Expression 1680 Specifications

Scanning Specifications

optical resolution	1600 x 3200 dpi
maximum resolution	13, 600 x 18, 720 dpi with interpolation
effective pixels	13, 600 x 18, 720 pixels (1600 dpi)
color depth	48 bits per pixel internal/external
grayscale depth	16 bits per pixel internal/external
scanning speed (color, 1600 dpi, draft mode)	9.2 msec/line (approx.)
scanning speed (grayscale/monochrome, 1600 dpi, draft mode)	3.1 msec/line (approx.)

Operating Environment

temperature operating range	41ºF to 95ºF (5ºC to 35ºC)
humidity operating range	10% to 80% (no condensation)
humidity storage range	10% to 85% (no condensation)

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption (operating without optional unit)	60W
power consumption (operating with optional unit)	75W
power consumption (standby without optional unit)	10W

Weight and Dimensions

maximum read area	8.5" x 11.7" (216mm x 297mm)
width	13.1" (332mm)
depth	22.1" (562mm)
height	5.2" (133mm)
weight	18.7 lb (8.5 kg approx.)
