Maintenance 15. Maintenance Parts List
G3 Rev.14 187
15.2 Parts by Environment Model
15.2.1 S: Standard-model
Part Name Code Note
Reference:
Maintenance
Overhaul *1
Ball Screw Spline 150 mm
R13B010220 11.1.1

Arm Cover
R13B030421
White
3.1
*1 As a rough indication, perform the overhaul (parts replacement) before reaching 20,000
operation hours of the Manipulator. The operation hours can be checked in [Controller
Status Viewer] dialog - [Motor On Hours].
For details, refer to Maintenance 2.2 Overhaul (Parts Replacement).
15.2.2 C: Cleanroom-model
Part Name Code Note
Reference:
Maintenance
Overhaul
*1
Ball Screw Spline 120 mm
R13B010221
11.1.2

Arm Cover
R13B030422
Plating
3.1
Bellows
R13B030704
*2
10
Gasket Unit
R13B031234 3
*1 As a rough indication, perform the overhaul (parts replacement) before reaching 20,000
operation hours of the Manipulator. The operation hours can be checked in [Controller
Status Viewer] dialog - [Motor On Hours].
For details, refer to Maintenance 2.2 Overhaul (Parts Replacement).
*2 Common with LS3 series.
The bellows are provided in a unit of one piece. The upper and lower bellows have
the same shape.
