Epson G3 Series

Setup & Operation 2. Specifications
26 G3 Rev.14
G3-301CM
G3-351CM
a
170
220
b
Max.410
Max.450
shaft diameter
Max.ø11 through hole
mechanical stop diameter
Conical hole
Ø3,90°
1 mm flat cut
Detail of “A”
(Calibration point position of Joints #3 and #4)
(*) indicates the stroke
margin by mechanical stop.
Reference through hole
(View from the bottom of the base)
or more Space for cables
