Epson G3 Series

Setup & Operation 3. Environments and Installation
34 G3 Rev.14
54
35
49
11
82
44
Power Cable
Connector (Straight)
Signal Cable
Connector
83
76
Power Cable
Connector
(L-shaped
)
35
RC700-A
Do not remove the M/C cables from the Manipulator.
For environmental conditions regarding space when placing the Controller on the base
table, refer to the Controller manual.
WARNING
■
To ensure safety, a safeguard must be installed
for the robot system.
For details on the
safeguard, refer to the EPSON RC+ User’s Guide.

NOTE
