Maintenance 4. Cable
90 LS Rev.10
M/C Cable
Installation
(
1) Install the Connector Sub Plate with the new M/C Cable to the Connector Plate.
For details, refer to Maintenance: 3.4 Connector Sub Plate.
(
2) Connect the connectors. (Connect to the Cable Unit with the same number.)
(
3) Mount the Connector Plate.
For details, refer to Maintenance: 3.3 Connector Plate.
(
4) Connect the power cable and signal cable connectors to the controller.
(
5) Turn ON the Controller.
(
6) If the connector falls off from the battery board, execute the calibration for all axes.
For details, refer to Maintenance: 13 Calibration.
