Maintenance 5. Arm #1
LS Rev.10 97
(6)
Apply grease (SK
-1A) inside the flexspline.
Grease volume LS3: 19 g
LS6: 37 g
(7)
Mount the Joint #5 motor.
Follow the installation steps in
Maintenance: 5.1 Replacing Joint #1 Motor.
