Maintenance 6. Arm #2
102 LS Rev.10
(5)
Mount the User Plate.
For details, refer to
Maintenance: 3.5 User Plate.
(6)
Connect the connectors X221, X21.
(7)
Bind
the cables with a wire tie in their original positions as before removed in the
r
emoval step (6).
Do not
allow unnecessary strain on the cables.
(8)
Mount the Arm Top Cover.
For details, refer to
Maintenance: 3.1 Arm Top Cover.
(9)
Execute
the calibration for Joint #2.
For details refer to
Maintenance: 13. Calibration.
