Epson LS3-401 series

Maintenance 8. Arm #4
LS Rev.10 125
(6)
Connect the connectors X241 and X41.
(7)
Mount the User Plate
.
For details, refer to
Maintenance: 3.5 User Plate.
(8)
Mount the control board.
For details, refer to
Maintenance: 11.3 Replacing the Control Board.
(9)
Bind
the cables with a wire tie in their original positions
as before removed in removal
step (5).
Do not allow unnecessary strain on the cables.
(10)
Mount the Arm Top Cover.
For details, refer to
Maintenance: 3.1 Arm Top Cover.
(11)
Execute the calibration of Joint #4.
For details on the calibration method, refer to Maintenance: 13. Calibration.
