Epson LS3-401 series User Manual

Setup & Operation 4. Setting of End Effectors
52 LS Rev.10
Calculating the Moment of Inertia
Refer to the following examples of formulas to calculate the moment of inertia of load
(end effector with work piece).
The moment of inertia of the entire load is calculated by the sum of each part (a), (b), and
(c).
Work piece (b)
Work piece (c)
End effector (a)
Joint #3 shaft
Rotation center
Moment of inertia
of end effector (a)
=
Moment of inertia
of work piece (b)
+
Moment of inertia
of work piece (c)
+
Whole moment
of inertia
The methods for calculating the moment of inertia for (a), (b), and (c) are shown below.
Calculate the total moment of inertia using the basic formulas.
(a) Moment of inertia of a rectangular parallelepiped
h
b
L
Mass (m)
Rectangular parallelepiped
’s center of gravity
Rotation center
m
+ m × L
2
b
2
+ h
2
12
(b) Moment of inertia of a cylinder
m
+ m × L
2
r
2
2
Mass (m)
L
r
Cylinder’s center of gravity
Rotation center
