122 Options and Consumables
4. Hold the cut-sheet feeder in both hands and press on the latch
levers. Fit the notches in the cut-sheet feeder over the
mounting posts on the printer. Releasing the latch levers locks
the cut-sheet feeder in place.
* latch lever
5. Slide the left paper guide so it is aligned with the triangle
mark. Next, slide the right paper guide to roughly match the
width of your paper. Slide the paper support midway
between the paper guides.
*

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
