Epson LX 300+II User Manual

Troubleshooting 109
5
5
5
5
5
5
5
5
5
5
5
5
Options
When you use the cut-sheet feeder, the paper does not
feed properly
The paper does not feed.
Cause What to do
The cut-sheet feeder may be
incorrectly installed on the
printer.
Reinstall it as described under
“Cut-sheet feeder” on page 121.
The paper release lever may be
in the wrong position.
Check that the paper release lever is
pushed back to the single-sheet position.
You may have loaded too
many sheets in the bin.
Remove some sheets. See “Paper” on
page 146 for information on the types
and quantity of paper that can be loaded
with the cut-sheet feeder.
Pap er ma y b e j am me d n ea r t he
print head.
Look for a paper jam.
The edge guide positions may
be incorrect.
Position the edge guides at the
diamond-shaped guide marks.
There may be only one sheet
left in the bin.
Add more paper.
Two or more sheets feed at one time.
Cause What to do
You may have loaded too
many sheets in the bin.
Remove some sheets. See “Paper” on
page 146 for information on the types
and quantity of paper that can be loaded
with the cut-sheet feeder.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
