Epson LX 300+II User Manual

106 Troubleshooting
Paper Handling
Single sheets do not feed properly
Paper does not feed.
Cause What to do
Continuous paper may be left
in the printer.
Remove the continuous paper. Set the
paper release lever to the single-sheet
position. Insert a new sheet.
The paper on the paper guide
is positioned too far to the left
or right far the printer to detect
that it is there.
Move the paper (and the edge guides) a
little to the left or right.
Paper feeding is crooked or the paper jams.
Cause What to do
The paper was not fed
correctly or is of the wrong
type.
Turn off the printer and pull out the
paper. Insert a new sheet straight into
the paper guide. Make sure you’re using
the right type of paper. See the paper
specifications under “Printer
Specifications” on page 141.
Paper does not eject completely.
Cause What to do
The paper may be too long. Press the LF/FF button to eject the page.
Use paper that is within the specified
range. See the paper specifications
under “Printer Specifications” on page
141.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
