Options and Consumables 121
6
6
6
6
6
6
6
6
6
6
6
6
Chapter 6
Options and Consumables
Installing and Using Options
Cut-sheet feeder
The optional single-bin cut-sheet feeder (C80637 for
LX-300+II/C80639for LX-1170II) handles up to 50 sheets of
standard bond paper (82 g/m² or 22 lb) without reloading.
Follow these steps to install the cut-sheet feeder:
1. Make sure the printer is turned off. Remove the paper guide
and open the paper guide cover.
2. If the tractor is installed in the pull-tractor position, remove it
and reinstall it in the push-tractor position.
3. Make sure the paper release lever is in the single-sheet
position.

Table of Contents

Other manuals for Epson LX 300+II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson LX 300+II and is the answer not in the manual?

Epson LX 300+II Specifications

Power IconPower
rated voltage120V AC
input voltage range99 to 132V, 198 to 164V
rated frequency range50 to 60 Hz
input frequency range49.5 to 60.5 Hz
power consumptionApprox. 23W (ISO/IEC 10561 Letter Pattern)
Performance IconPerformance
print speed high speed draft337 cps (12 cpi)
print speed draft225 cps (10 cpi)
print speed near letter quality56 cps (10 cpi)
sound level49 dBA (ISO 7779 pattern)
mtbf6, 000 POH (25% duty cycle)
print head life400 million characters
ribbon life3 million characters (draft, 10 cpi, 14 dots/character)
Weight and Dimensions IconWeight and Dimensions
carton dimensions14.5" x 17.6" x 8.6" (W x D x H)
carton weight12.10 lb
height6.26" (159 mm)
width14.42" (366 mm)
depth10.84" (275 mm)
weight9.7 lb (4.4 kg)
