Epson LX 300+II User Manual

Printer Software 57
3
3
3
3
3
3
3
3
3
3
3
3
2. Click the Monitoring Preferences button. The Monitoring
Preferences dialog box appears.
3. The following settings are available:
Select Notification Displays the error item check box On/Off status.
Turn on this check box to display the selected
error notification.
Select Shortcut
Icon
The selected icon is displayed on the taskbar.
The setting’s example is shown on the right
window. By clicking the shortcut icon, you can
access the Monitoring Preferences dialog box
easily.
Receive error
notification for
shared printers
Error notification for a shared printer can be
received when this check box is selected.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
