Epson LX 300+II User Manual

78 Printer Software
2. Insert the CD-ROM, then the EPSON Installation Program
dialog box appears. Cancel the dialog box by clicking
Cancel, then type the appropriate drive and folder names in
which the printer driver for clients is located, then click OK.
When installing drivers in Windows Vista, XP or 2000,
“Digital Signature is not found.” may appear. Click Yes (for
Windows 2000), Continue Anyway (for Windows XP) or
Install this driver software anyway (for Windows Vista) and
continue installing.
The folder name differs depending on the OS being used.
3. Select the name of the printer, then click OK. Then follow the
on-screen instructions.
Note:
❏ If you also want to install EPSON Status Monitor 3, see “Installing
EPSON Status Monitor 3” on page 59 for instructions.
Client’s OS Folder Name
Windows 98 \<Language>\WIN98
Windows Me \<Language>\WINME
Windows XP, 2000 \<Language>\WIN2000
Windows Vista x86 Edition \<Language>\WINVISTA
Windows XP Professional
x64 Edition, Vista x64
Edition
\<Language>\WINVISTA_XP64
Windows NT 4.0 \<Language>\WINNT40

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
