EPSON Stylus C50/C60/C61/C62 Revision C
Disassembly and Assembly Disassembly 94
3. Move the protrusion of the Upper housing, which contacts USB interface, to the
right side slightly by using the precision screwdriver (-).
Figure 4-6. Protrusion position of the Upper housing
CAUTION
Do not damage the protrusion by the precision screwdriver (-).
When assembling the Upper housing to the printer,
Make sure that the lower metal fittings for locking the
Parallel interface is on the Housing.
Make sure that seven hooks of the Upper housing is correctly
fixed to the Lower housing.
Make sure that there is not the clearance between the Upper
housing and the Lower housing.
USB interface
