Epson Stylus C62 User Manual

EPSON Stylus C50/C60/C61/C62 Revision C
Appendix Parts List 170
7.4 Parts List
<Stylus C50>
Table 7-19. Stylus 50 parts list
Code Parts Name
100 HOUSING,UPPER ASSY.,C429
101 PAPER SUPPORT
102 STACKER ASSY.,C429
104 LBUTTON,SW;B
200 BOARD ASSY.,MAIN
300 POWER SUPPLY ASSY.,C429;220V
400 POWER CABLE
500 PRINTER MECHANISM(ASP)MA612-100
501 PRINT HEAD
502 CARRIAGE
503 COVER,CARTRIDGE,BK;D
504 COVER,CARTRIDGE,C
505 CABLE,HEAD
507 MOUNTING PLATE,M/B
508 HOLDER,SHAFT ASSY.,C418
509 MOTOR ASSY.,CR
510 HOUSING,LOWER ASSY.,C429
512 FRAME,FRONT ASSY.,C429
514 TORSION SPRING RIGHT,SHAFT,CR GUIDE
515 TORSION SPRING LEFT,SHAFT,CR GUIDE
516 SHAFT,CR,GUIDE;B
517 SPACER,FFC
518 PLATE SPRING,COVER,CARTRIDGE
519 HOLDER,CABLE HEAD;B
604 C.B.P-TITE SCREW,3X8,F/ZN
605 C.B.S. SCREW(B300204211)
700 EDGE GUIDE
701 HOPPER ASSY.,C429
703 COMPRESSION SPRING,2.50
704 FRAME,ASF
705 HOLDER,PAD ASSY.,C429
707 TORSION SPRING,29.1
708 POROUS PAD,INK EJECT
709 POROUS PAD,TUBE,STOPPER
710 C.B.S-TITE(P4),3X6,F/ZN
711 C.B.S. SCREW(B300204211)
712 C.B.P-TITE SCREW,3X8,F/ZN
713 SHIELD PLATE,M/B
714 C.B.S. SCREW(B300204611)
1 INDIVIDUAL CARTON BOX FOR PACIFIC
3 PAD,PRINTER
4 PAD,ACCESSORY
5 PLASTIC PROTECTIVE BAG,650X420X0.03T
7 PAD,CR
Table 7-19. Stylus 50 parts list
Code Parts Name

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
