Epson Stylus C62 User Manual

EPSON Stylus C50/C60/C61/C62 Revision C
Appendix Parts List 171
<Stylus C60>
Table 7-20. Stylus C60 parts list
Code Parts Name
100 HOUSING,UPPER
101 COVER,PRINTER
102 PAPER SUPPORT
104 LOGO PLATE 10X40;C
105 BUTTON,SW;EFS
106 STACKER
107 STACKER,SUPPORT,UPPER
108 STACKER,SUPPORT,MIDDLE
109 SHAFT,STACKER
200 BOARD ASSY.,MAIN
300 POWER SUPPLY ASSY.,C418;120V
500 PRINTER MECHANISM(ASP)MA610-100
501 PRINT HEAD
502 CARRIAGE
503 COVER,CARTRIDGE,BK;B
504 COVER,CARTRIDGE,C
505 CABLE,HEAD
507 MOUNTING PLATE,M/B
508 HOLDER,SHAFT ASSY.,C418
509 MOTOR ASSY.,CR
510 HOUSING,LOWER
511 FOOT
512 FRAME,FRONT ASSY.,C418
514 TORSION SPRING RIGHT,SHAFT,CR GUIDE
515 TORSION SPRING LEFT,SHAFT,CR GUIDE
516 SHAFT,CR,GUIDE
517 SPACER,FFC
518 PLATE SPRING,COVER,CARTRIDGE
519 HOLDER,CABLE HEAD;B
604 C.B.P-TITE SCREW,3X8,F/ZN
605 C.B.S. SCREW(B300204211)
606 +.BIND B-TITE SEMS W2,2.5X5,F/ZB
700 EDGE GUIDE
701 HOPPER
702 PAD,HOPPER
703 COMPRESSION SPRING,2.50
704 FRAME,ASF
705 HOLDER,PAD
706 PAD,LD;D
707 TORSION SPRING,29.1
708 POROUS PAD,INK EJECT
709 POROUS PAD,TUBE,STOPPER
710 POROUS PAD,CAP,LOWER
711 C.B.S. SCREW(B300204211)
712 C.B.P-TITE SCREW,3X8,F/ZN
713 SHIELD PLATE,M/B
714 C.B.S. SCREW(B300204611)
1 INDIVIDUAL CARTON BOX FOR AMERICA
Table 7-20. Stylus C60 parts list
Code Parts Name

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
