Epson Stylus C62 User Manual

EPSON Stylus C50/C60/C61/C62 Revision C
Appendix Parts List 172
<Stylus C61/62>
3 PAD,PRINTER
4 PAD,ACCESSORY
5 PLASTIC PROTECTIVE BAG,650X420X0.03T
7 PAD,CR
Table 7-21. Stylus 61/C62 parts list
Code Parts Name
100 HOUSING,UPPER ASSY
101 COVER, PRINTER ASSY., C62
102 PAPER SUPPORT EDG2
104 STACKER ASSY
200 BOARD ASSY.,MAIN
300 POWER SUPPLY ASSY
400 POWER CABLE
500 PRINTER MECHANISM(ASP)MA613-100
501 PRINT HEAD
502 CARRIAGE;B
503 COVER,CARTRIDGE,BK;ASSY
504 COVER,CARTRIDGE,C ASSY
505 CABLE,HEAD;B
506 POROUS PAD, INK EJECT;B
507 POROUS PAD, TUBE, STOPPER;B
508 HOLDER SHAFT ASSY
Table 7-20. Stylus C60 parts list
Code Parts Name
509 MOTOR ASSY.,CR
510 INSULATOR, MOTOR, CRi
511 FOOT
512 FRAME, FRONT ASSY, C418
513 SLIDER, CR
514 TIMING BELT
516 SHAFT,CR,GUIDE;B
519 HOLDER,CABLE HEAD;B
520 POROUS PAD, SLIDER, CAP
604 C.B.P-TITE SCREW,3X8,F/ZN
605 C.B.S. SCREW(B300204211)
606 +.BIND B-TITE SEMS W2, 2.5x55,F/ZB
700 ASF UNIT
703 COMPRESSION SPRING, 2.50
711 C.B.S. SCREW(B300204211)
712 C.B.P-TITE SCREW,3X8,F/ZN
714 C.B.S. SCREW(B300204611)
01 INDIVIDUAL CARTON BOX
03 PAD,PRINTER
04 PAD,ACCESSORY
05 PLASTIC PROTECTIVE BAG,650X420X0.03T
06 PAD, STACKER
07 PAD,CR;B
Table 7-21. Stylus 61/C62 parts list
Code Parts Name

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
