EPSON Stylus C50/C60/C61/C62 Revision C
Operating Principles Electrical Circuit Operating Principles 53
2.2.3.1 Main Elements
Table 2-11 shows the function of the each main elements on C483/C484 Main-B
board.
Table 2-11. Main elements (Stylus C61/C62)
IC Location Function
CPU
E01A37**/39**
IC8
CPU mounted on the MAIN board is driven by clock
frequency 48 MHz, 24MHz and controls the printer.
DRAM IC1/IC2 Bus= 16 bit, 4M/16Mbit DRAM
EEPROM IC5
1kbit EEPROM
• Default value setting
• Parameter backup
Reset Regulator IC
BN6150F-E2
IC3
Reset IC
• For +5V; reset when +4.2V is detected
• For +42V, reset when +35.8V is detected
Common Driver
E09A29LA
IC10
Head drive control HIC
• Generates head common voltage.
Motor Driver IC6 PF/CR motor drive IC
Parallel I/F IC
SN74LVCZ16128
4AGT
IC7 IEEE1284 parallel I/F transceiver IC.

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
