Epson TM-C3500 Series Developer's Guide

18
Barcode Print Direction
Barcode print direction and name are as follows.
When printing ladder barcodes, it may not be possible to read the barcode with a barcode
reader if printed straddling the feeding position. (U“Checking the Feeding Position” on page
35) For this reason, it is recommended to use fence barcodes or set the Print Quality to
Quality (Mode2).
8 1 0 1 0 5 4 3 2 1 1 2 0 0
8 1 0 1 0 5 4 3 2 1 1 2 0 0
Paper feed direction
Fence barcode
Ladder barcode

Epson TM-C3500 Series Specifications

General

Print Technology	Inkjet
Print Resolution	Up to 720 x 360 dpi
Ink Type	Pigment-based ink
Interface	USB 2.0, Ethernet
Media Handling	Roll paper
Operating System Support	Windows, Mac OS
Dimensions	310 x 283 x 261 mm
Weight	Approx. 12 kg
Media Width	30 to 112 mm
Media Type	Synthetic
Cutter	Auto cutter
Ink Cartridges	Individual ink cartridges (cyan, magenta, yellow, black)
Print Speed	Up to 103 mm/sec
