Epson TM-C3500 Series - Die-Cut Labels (Black Marks) and Roll Paper

70
Die-cut Labels (Black Marks) and Roll Paper
When Borderless Printing Enabled
Margins at top, bottom, right, and left (inside label): 0 mm (typical value)
Q Note
The maximum value of the print area width is 104 mm.
Backing paper width
0.5 to 1.0 mm
15.0 mm or more*1
18.0 mm or more*2
1.5 mm
Auto cut position
Paper feed
direction
Print area
Print area width
Label
1.5 mm
Paper width
center
Waste part
2.0 mm
1.5 mm
Auto cut position
Backing paper
Waste part 2.0 mm
Auto cut position
Perforation position
Black mark position
(back side)
*1: When not auto cutting,
8.0 mm or more
*2: When not auto cutting,
11.0 mm or more
