Epson TM-C3500 Series Developer's Guide

87
Roll Paper Handling
Paper formats that can be handled are as follows.
• Continuous paper (black marks)
• Die-cut labels (black marks)
• Die-cut labels (gaps)
• Die-cut labels with transparent backing paper
Paper Handling Procedures
• Continuous paper (black marks) and die-cut labels (black marks)
Set a margin of 107.5 mm or more between the end edge of the paper and the end edge of the
final ticket or label printed. Do not set the label so that it is located less than 107.5 mm from the
end edge of the paper. This area must only consist of backing paper. Affix two black marks
behind the final ticket or label printed.
Q NOTE
If new print data is sent to this printer after print processing (including auto
cut) of the final ticket or label has completed normally, a Media Size Error
will occur, and the printer will stop with the print data retained.
Max. 11 mm
5 ±0.5 mm
Max. 11 mm
5 ±0.5 mm
107.5 mm or more
107.5 mm or more
Roll paper core
Roll paper core
End edge of last label
End edge of last label
Paper feed direction
Paper feed direction
Continuous paper (black marks)
Die-cut labels (black marks)

Epson TM-C3500 Series Specifications

General

Print Technology	Inkjet
Print Resolution	Up to 720 x 360 dpi
Ink Type	Pigment-based ink
Interface	USB 2.0, Ethernet
Media Handling	Roll paper
Operating System Support	Windows, Mac OS
Dimensions	310 x 283 x 261 mm
Weight	Approx. 12 kg
Media Width	30 to 112 mm
Media Type	Synthetic
Cutter	Auto cutter
Ink Cartridges	Individual ink cartridges (cyan, magenta, yellow, black)
Print Speed	Up to 103 mm/sec
