Chapter 1 Product Overview
25
1
Paper Specifications
80 mm width paper setting 58 mm width paper setting
Paper types Specified thermal paper
Form Roll paper
Size Roll paper diameter 83 mm {3.27"} maximum
Roll paper spool Inside: 12 mm {0.47"}, Outside: 18 mm {0.71"}
Roll width when taken up 80 + 0.5/-1.0 mm 58 + 0.5/-1.0 mm
Paper width 79.5 ± 0.5 mm 57.5 ± 0.5 mm
Specified roll paper type NTP080-80 NTP058-80
• Paper must not be pasted to the roll paper spool.
• For the best print quality for each paper type, it is recommended to set the print density.
(See "Setting the Memory Switches/Receipt Enhancement" on page 43.)
