Epson TM-T20 Technical Reference Guide

Chapter 4 Handling
77
4
Removing Jammed Paper
When a paper jam occurs, never pull out the paper forcibly. Turn off the printer power, open the
roll paper cover, and then remove the jammed paper.
When the Roll Paper Cover Cannot be Opened
When the roll paper cover cannot be opened due to jammed paper, follow the steps below to
open it.
1
Turn off the printer.
2
Slide the cutter cover toward the front to open it.
CAUTION
Do not touch the thermal head. (See"Cleaning the Printer" on page 79.)
It can be very hot after printing.
Cutter cover
Indent

Epson TM-T20 Specifications

General

Autocutter	Yes
Print Method	Line thermal
Paper Width	79.5 ±0.5 mm
Interface	USB, Ethernet
Dimensions	140‎ x 199 x 146 mm (Width x Depth x Height)
Power Supply	External power supply
Paper Thickness	0.06 - 0.085 mm
