Chapter 2 Setup
41
2
Connecting the Ethernet interface cable
Connect a 10/100BASE-T cable to the 10/100BASE-T LAN connector by pressing firmly until the
connector clicks into place.
CAUTION
• When LAN cables are installed outdoors, make sure devices without proper surge
protection are cushioned by being connected through devices that do have surge
protection.
Otherwise, the devices can be damaged by lightning.
• Never attempt to connect the customer display cable, drawer kick-out cable, or a
standard telephone line cable to the 10/100BASE-T LAN connector.
To use the Ethernet interface, the IP Address Setup Utility for UB-E03 is required. For
detailed information about the setup methods, see “Setting IP Address Using EPSON
TMNet WinConfig“, “Setting IP Address Using arp/ping Command“, “Checking/Changing
the Settings“, “Initializing“, and “ESPON TMNet WebConfig” in the UB-E03 Technical
Reference Guide. You can obtain the IP Address Setup Utility for UB-E03 and the UB-E03
Technical Reference Guide from one of the following URLs or ask your dealer:
• For customers in North America, go to the following web site:
http://www.epsonexpert.com/
• For customers in other countries, go to the following web site:
http://www.epson-pos.com/
10/100BASE-T LAN
interface connector
Button
Press down the button for a
while when the power is on to
initialize to the factory settings.
LED (Green)
LED (Yellow)
