Maintenance 5. Backup and Restore
VT Rev.1 129
5.3 Backup
Backup the Manipulator status from EPSON RC+ 7.0.
(1) Select EPSON RC+ 7.0 menu-[Tools]-[Controller] to display the [Controller Tools]
dialog.
(2) Click the <Backup Controller…> button to display the [Browse For Folder] dialog.
(3) Specify the folder to save the backup data. Create a new folder if desired.
(4) Click the <OK> button. A folder is created in the specified folder containing the
backup data with a name in the following format.
B_VT_ serial number_ date status was saved
→ Example: B_VT_12345_2016-04-03_092941
CAUTION
■
Do not edit the backup files. Otherwise, operation of the robot system after data
restoration to the Manipulator is not assured.
