Printer Basics

Part Names and Functions

Paper cassette 1 (C1) Loads paper.

Paper cassette 2, Paper cassette 3, Paper cassette 4 (C2,

C3, C4)

Optional paper cassette units. Loads paper.

Cabinet Optional cabinet. Stores paper or other consumables.
