Installation Location and Space

Secure enough place to install and operate the printer correctly.

A 681 mm

B 965 mm

C 515 mm

D 448 mm

E 517 mm

See "Safety Instructions" in this manual to conrm the environmental conditions.

Related Information

& “Advisories and Warnings for Setting Up the Printer” on page 14
