• Cellular modem Antenna : connector SMA-Female
• Power supply: +7.2 to +32 V
DC
(4-pin micro-FIT connector) (+8 à 32V
DC
with battery option)
• 1 RS232 serial port (300 to 115200bds) Sub-D 15 pin female
• 1 RS485 port with spring Contact
• AT Commands : GSM 07.05 et 07.07
• SIM reader format mini SIM 2FF (SIM 3V – 1,8V)
• 3 opto-coupled inputs
• 1 open collector output
• 1 analog input (0 – 10 Volts)
• Cable with 4-wire Micro FIT connector (Power supply, Input and Output)
• Cable with 2-pin Micro FIT connector (Input and Output)
Options / Additional accessories *
• Analog input (0 – 10 Volts) S0534
• Backup battery, RTC back up S0531
• ONE WIRE Multi slaves S0535
• EaseIP application S0519
• NTRIP application S0445
• Embedded software development kit SDK EGM
• Recommended antenna 636Z232160
For another antenna solution, please contact ercogener
• Accessories: cables, power supplies... (information available on our website)
* These options are in addition or replace some existing options, contact us (see § 3.3.2 Functional
architecture of optional serial ports )
