Ercogener GenPro 425e - Cellular Reception Quality

EG_GenPro425e_1103_UG_001_UK.docx
Page 45 / 51
Descriptions and non-contractual illustrations in this document are given as an indication only.
ercogener reserves the right to make any modifications.
Dct_427_02
5.6.1 Response with modem attached to 2G network
Table 38 : RSSI value (rxlev)
Value of <rssi>
Gain in dbm
Interpretation
Value of <ber>
Interpretation
0
<= -110 dbm
Insufficient
0 to 7
See Standards ETSI
GSM 05.08
1 to 15
-110 to -96 dbm
Insufficient
16 to 62
-95 to -49 dbm
Sufficient
63 (max)
>= -48dbm
Perfect
99
Unknown/not detectable
99
Unknown/not detectable
Example:
+COPS:0,0,"FirstOne",3
<Act> = 3, attached to 2G network
+CESQ: 52,0,255,255,255,255
Rxlev is the gain in steps of 1. 1->-110dBm, 2-> -109dBm …
Rxlev=52, RSSI= -59dBm
5.6.2 Response with modem attached to 3G network
Table 39 : RSCP value
Value of <rscp>
Gain in dbm
Interpretation
Value of <ecn0>
Interpretation
0
<=121 dbm
Insufficient
0 to 49
See standard 3GPP TS
25.133
1 à 15
-120 à -106 dbm
Insufficient
16 à 95
-105 à -26 dbm
Sufficient
96
>= -26dbm
Perfect
255
Unknown/not detectable
255
Unknown/not detectable
Example:
+COPS:0,0,"FirstOne",6
+CESQ : 99,99,47,44,255,255 RSCP is the gain in steps of 1. 47-> -74dBm
5.6.3 Response with modem attached to 4G network
Table 40 : RSRP value
Value of <rscp>
Gain in dbm
Interpretation
Value of
<rsrq>
Interpretation
0
<=141 dbm
Insufficient
0
<=-19dB
1 à 15
-140 à -126 dbm
Insufficient
1 à 33
-19.5 à -3.5dB pas 0.5dB
16 à 96
-125 à -45 dbm
Sufficient
34
>= -3dB
97
>= -44dbm
Perfect
255
Unknown/not detectable
255
Unknown/not detectable
Example:
+COPS:0,0,"FirstOne",7
+CESQ : 99,99,255,255,24,38 RSRP is the gain in steps of 1. 38-> -103dBm RSRQ (24) -8dB
