SpiroSphere
®
ECG Instructions for Use
Page 32/136
Version 02.02 • 04AUG2022
The lower section displays the
quality assessment according to
ATS/ERS 2005 guidelines:
= no acceptability errors
= minor errors present
= major errors present
Screen display ow-volume and
tiffaneau curve:
Screen display volume-time
curve:
Change View:
Curves superimposed:
Tap on the curve you want to be
displayed.
Print Report
Return to Patient Details
Return to Home Screen
Individual parameter Repeatability
= Parameter repeatability criteria not met
= Parameter repeatability criteria met
Overall Repeatability
= Not enough effort performed
= Enough efforts, but one or more repeatability criteria are not met
= Enough efforts and all repeatability criteria are met
To Next Page
