13 - EXPLODED VIEW AND PARTS LIST
13 - A - GENERAL ASSEMBLY
ITEM DESCRIPTION ILLUSTRATION
001A VENTILATION ASSEMBLY 1
010A HIGH PRESSURE ASSEMBLY 2
020A LOW PRESSURE ASSEMBLY 3
030A PISTON DRIVE ASSEMBLY 4
040A CASING COVER 5
