7 - C - FIRST START- UP
7 - C - 1 REMOVAL FROM STORAGE
) Drain the storage oil from the compressor carefully.
) Fill the compressor with the recommended oil.
(see chapter "General Characteristics of recommended oil").
) Start the compressor and run for 15 minutes off load, increase pressure to maximum
service pressure for 15 minutes.
Wait for 30 minutes before draining the oil.
) Fill the compressor with the recommended oil .
) For oil level and draining see chapter "Lubrication of Compressors".
7 - C - 2 COUPLING MOUNTING
This coupling has been specially designed to absorb vibrations and variations between the
compressor and its drive motor. It can be used with an electric motor drive as well as a
combustion engine.
- COUPLING TYPE ...................................................... AC2
- NUMBER OF BLADES .............................................. 24
- MAXIMUM POWER TRANSMITTED ......................... 15 hp - 11kW
It is absolutely necessary that after mounting, both plates should move angularly in relation to
each other.
The measurement between these two plates must be maintained while mounting.
Under no circumstances must the two plates be bonded together.
BREAKING OF SEMI-FLEXIBLE BLADES
This is systematically due to a fault in the alignment between the drive motor and compressor
or to a fault in the distance between the plates (plates bonded together or the plates too far apart).
In case of breaking of the operating blades, check these two conditions.
IMPORTANT :
IN THE SEMI-ELASTIC ERVOR COUPLING, DRIVING AND ABSORBTION
OF VIBRATIONS BETWEEN THE DRIVE MOTOR AND THE
COMPRESSOR ARE EFFECTED THROUGH THE SEMI-ELASTIC
BLADES.
!
