Page 8
ERVOR (SCA) - 6, Rue Désiré Granet - Z.I. du Val d'Argent - 95100 ARGENTEUIL FRANCE
(33) 01 34 11 50 00 (33) 01 34 11 50 10
Web : www.ervor.com - Email : info@ervor.com
Manual G06
Edition: 10/2015 - rev A
2 - TECHNICAL CHARACTERISTICS
2 - A - TECHNICAL DESCRIPTION
- Reciprocating air compressor with lubricated stroke
- Maximum Output Pressure .......................................... 40 bar
- Service Pressure ........................................................ 0 to 40 bar
- Low pressure cylinder bore ......................................... 125 mm
- High pressure cylinder bore ........................................ 50 mm
- Piston stroke .............................................................. 38 mm
- Revolution speed: -Maximum : 1500 rpm
-Minimum : 600 rpm
- Forced air cooling by outward-flow turbine
-heat abstraction : 5.1 kW
4000 kCal/h
- Cooling ...................................................................... copper coil between stages
- Oil Splash Lubrication
- Powered by electric motor or combustion engine (petrol or diesel)
- Direct coupling with semi-elastic blades or indirect coupling by drive pulley and belts
- Ambient temperatures for operation with standard equipment from -10°c to +40°c
- Weight with AC2 coupling ........................................... 60 Kg approx
- Oil capacity ................................................................ 1.9 Litres approx
2 - B - MATERIAL DESCRIPTION
Casing :
Cast iron. Large oil capacity. Oil fill in top.
Dust-proof. Oil level sight glass.
Vent pipe from casing to the air filter.
Crankshaft :
Steel, with double bearing, and counterweight.
Connecting rod :
Aluminium, free moving on the crank shaft with bronze bush.
Piston :
Aluminium monobloc piston. Large bore, short stroke and low linear velocity.
