TO ORDER SPARE PARTS, SEE CHAPTER 12.
ILLUSTRATION N° 2
ITEM QUANTITY DESCRIPTION
SPARE PARTS
REFERENCE
REFERENCE
001A 1 Cylinder gasket 8 970 174 7 500 102
010A 1 High pressure cylinder (standard version) 3 931 012 3 931 012
010B 1 High pressure cylinder (Llyod's version) 3 931 024 3 931 024
010C 1 High pressure cylinder (Bureau Veritas) 3 931 016 3 931 016
020A 4 Soc.hd.cap screw M10 x 40 7 402 004
030A 4 Crinkle washer 7 421 001
040A 1 HP cylinder head gasket 8 970 174 3 500 005
050A 2 Valve stem 8 970 177 3 925 002
060A 1 Intake stop 8 970 177 3 936 007
070A 4 Valve spring Ø30 8 970 177 3 933 012
080A 1 High pressure cylinder head 8 970 179 3 932 008
090A 2 High pressure valve Ø30 8 970 177 3 933 003
100A 4 Belleville washer 8 970 177 7 421 009
110A 2 Castellated nut 8 970 177 3 933 024
120A 2 Split pin 8 970 177 7 436 004
130A 1 High pressure manifold gasket 8 970 174 3 500 006
140A 1 Connection 1/2" pipe Ø18 8 141 513 7 650 006
150A 1 High pressure manifold (standard version) 3 934 030 3 934 030
150A 1 High pressure manifold (version Llyod's) 3 934 035 3 934 035
160A 2 Soc.hd.cap screw M8 x 20 7 402 038
170A 6 Soc.hd.cap screw M8 x 40 7 402 042
-
180A 1 Plug 1/2" 7 603 031
-
190A 1 Soc.hd.cap screw M8 x 20 7 402 038
200 1 Compression stop 8 970 177 3 936 019
(
-
) This part is not illustrated
